APC_INDEX_MISMATCH on a Lenovo Laptop: How to Fix It

APC_INDEX_MISMATCH is a driver synchronization error — a driver made kernel calls in the wrong order, and Windows crashed rather than risk corruption. On Lenovo laptops, this stop code has a famous prime suspect: the Realtek audio driver. If your crashes mention rtkvhd64.sys or happen during audio use, you’re likely one driver update away from fixed.

Work through these in order. For the Windows 10 variant, see APC index mismatch on Windows 10 ; if it started after an update, see APC index mismatch after a Windows 11 update .

Why this happens

• Realtek HD audio driver bug: The classic Lenovo trigger — mismatched APC calls in certain driver versions.
• Outdated graphics driver: Intel/NVIDIA/AMD graphics drivers with similar kernel-call issues.
• Wrong driver from Windows Update: Generic Realtek driver replacing Lenovo’s tuned version.
• Corrupted system files: Damaged kernel components after failed updates.
• Third-party audio software: Equalizers, virtual audio cables, and audio enhancers hooking the audio stack.
• USB audio and DisplayLink drivers: External docks and USB headsets install their own audio drivers that can trigger the same mismatch — disconnect them as a test.
• BIOS/firmware mismatch: Old Lenovo BIOS with newer Windows builds.

How to fix it

Work through these in order — start with Fix 1 and stop as soon as the blue screens stop appearing.

Fix 1: Update the Realtek audio driver from Lenovo

The number-one fix for this stop code on Lenovo hardware.

1. Identify your exact model: press Win + R, type msinfo32, and note System Model.
2. Go to Lenovo Support , enter your model or serial number.
3. Download the latest Audio driver (Realtek HD Audio) listed for your machine.
4. Open Device Manager (Win + X > Device Manager), expand Sound, video and game controllers.
5. Right-click Realtek(R) Audio > Update driver > Browse my computer for drivers and point it at the downloaded Lenovo driver. Or run Lenovo’s installer directly.
6. Restart and test — especially with audio playing, since that’s the trigger.

Fix 2: Roll back the Realtek driver if crashes just started

If a recent driver update introduced the problem, reverse it.

1. In Device Manager, right-click Realtek(R) Audio > Properties > Driver tab.
2. Click Roll Back Driver, choose a reason, and confirm.
3. Restart and test.
4. Prevent Windows Update from reinstalling the bad version using the “show or hide updates” troubleshooter.
5. Check Lenovo Support periodically for a fixed driver release.

Fix 3: Update graphics and chipset drivers

The secondary suspects — update them while you’re at it.

1. In Device Manager, update Display adapters and System devices.
2. Install Lenovo’s tested chipset and graphics drivers from Lenovo Support .
3. Intel graphics users can also use the Intel Driver & Support Assistant .
4. Restart and monitor for a day of normal use.

Fix 4: Remove third-party audio software

Audio enhancers hook the same stack Realtek uses — conflicts are common.

1. Open Settings > Apps > Installed apps.
2. Uninstall equalizers, virtual audio devices, audio “boosters,” and old VoIP tools with their own audio drivers.
3. In Device Manager, under Sound, video and game controllers, uninstall any non-Realtek, non-Intel audio devices you don’t use (right-click > Uninstall device).
4. Restart and test audio playback.

Fix 5: Run SFC and DISM

Repairs kernel and system file damage that can manifest as APC mismatches.

1. Open an administrator Command Prompt.
2. Run sfc /scannow and wait.
3. Run DISM /Online /Cleanup-Image /RestoreHealth.
4. Restart and test.

Fix 6: Update Lenovo BIOS and run Lenovo diagnostics

Firmware-level fix plus a hardware sanity check.

1. On Lenovo Support , download the latest BIOS for your model.
2. Connect AC power and run the updater — don’t interrupt it.
3. After updating, run Lenovo Diagnostics (via the Lenovo Vantage app or F10 at boot on many models) to rule out hardware.
4. Retest for stability.

Fix 7: Disable the audio device as a diagnostic (temporary)

Confirms the audio driver is the culprit when nothing else is conclusive.

1. In Device Manager, right-click Realtek(R) Audio > Disable device.
2. Use the laptop (without sound) for a day.
3. No crashes? The Realtek driver is confirmed — re-enable it and focus on finding the right driver version (Fix 1), trying older Lenovo releases if the newest still crashes.
4. Crashes continue? Re-enable and investigate graphics/chipset drivers instead.

Fix 8: Confirm with the minidump and try Lenovo’s older driver

When the newest driver still crashes, the dump plus Lenovo’s driver archive usually ends it.

1. Check C:\Windows\Minidump for recent .dmp files — confirm the faulting module is the audio driver (rtkvhd64.sys) and not something else masquerading as this stop code.
2. On Lenovo Support , look beyond the latest audio driver: Lenovo keeps previous versions available for most models.
3. In Device Manager, uninstall the current Realtek driver (check Attempt to remove the driver for this device), restart, then install the older Lenovo version.
4. Block Windows Update from “upgrading” it again with the show/hide updates troubleshooter.
5. If two different Lenovo driver versions both crash, run the extended memory diagnostic (mdsched.exe) to rule out RAM before suspecting the motherboard.

Closing

APC_INDEX_MISMATCH on a Lenovo is a driver-sync problem with a usual suspect, and that suspect is the Realtek audio driver. Installing Lenovo’s version — not the generic one Windows Update prefers — ends most cases at Fix 1. If the newest Lenovo driver still crashes, don’t assume the hardware is broken: try the previous release, since Realtek regressions are common and Lenovo’s archive usually has older versions. Work the list in order, keep audio software minimal, and update the BIOS while you’re at it. This stop code looks exotic but it’s one of the most fixable blue screens there is — and once the right driver is in place, it stays fixed.
